Transfer Hose

HOSE

EGT's hot melt transfer hose uses a high-efficiency insulator to increase the heat retention rate and has a thin outer diameter, which is characterized by high convenience and efficiency.

Product Specifications

Length 120 cm, 180, 240, 300, 360, 420, 480~ (cm) / 4 ft, 6, 8, 10, 12, 14, 16~ (ft)
Inner Diameter 10, 12, 14, 16mm
Maximum Working Pressure 100 kgf/㎠ / 1422 psi
Maximum Heating Temperature 230℃ / 446℉ (OPTION : 250℃ / 482℉)

※ Minimum bend radius of hose: 8 inch

Electrical Specifications

Rated Voltage 220 VAC
Heater Calorie 26 ~ 40Watt / 30 cm(1 ft)
Temperature Sensor RTD
  • ※ Hose can be manufactured according to other user requirements. Please contact us.
  • - Can be ordered in increments of 30cm from the minimum length of 60cm
  • - Can be changed to other sensors such as thermocoupler (T.C)
